SPECIFICATIONS

• Wire :
  PVC UL 1803 / 18AWG.
  length : 1100±30mm
  Out diameter : 4.0mm
  Temperature tolerance range : -40ºC~105ºC
  Braid copper wires : 170 / 0.08mm
• Terminal :

  Right-angle 4mm nickel-plated brass banana plug with
  caged and insulated sheathing to avoid brass oxidation
• Rating :
  EN 61010-031:2015
  CAT IV 1000V 10A
• Probe tip type: AL-28-1: 2mm, AL-28-3: 4mm, AL-28-5: 2-4mm(screw spiral)
